Due to insurance reasons, we can only hire these to credit account customer
A low height of 1890mm and a narrow width of 1840mm enables this JCB Loadall to access the very smallest operating environments.
JCB’s innovative adaptive load control system automatically prevents your 525-60 Hi-Viz Telehandler from overturning forwards during heavy load handling.
JCB LiveLink now has the ability to monitor seatbelt usage, to ensure operators are safe when operating the machine. An auto regeneration feature on the Diesel Particulate Filter (DPF) enables maximum productivity and uncompromised performance. AutoStop on the new Stage V model automatically shuts off the engine whilst the 525-60 Hi Viz remains safely parked and not in operation. For excellent traction and performance in difficult conditions, we’ve fitted the JCB 525-60 Hi Viz telehandler with 4WD as standard.
Features
- 2500kg lift capacity
- 6m lift height
| Specifications | |
| Nominal load at COG | 2.5 t |
| Model Series | 525 |
| Centre of Gravity | 500 mm |
| Standard Tyres | 12x16.5 |
| Transmission Type | HY |
| Max Reach Horizontal | 3.06 m |
| Capacity at Full Forward Reach | 0.8 t |
| Lifting Height | 6 m |
| Capacity at Full Lift Height | 2 t |
| Weight | 5.49 t |
| Transport Length | 3.38 m |
| Transport Weith | 1.84 m |
| Transport Height | 1.89 m |
| Travel Speed | 20 km/h |
| Engine Manual | Kohler |
| Engine Power | 55 kW |
| Displacement | 2.5 l |
| Max Torque | 300/1500 Nm |
| Number of Cylinders | 4 |
